Ubiquiti Unifi U6 Mesh

Small, elegant, yet extremely powerful Dual-Band AP with support for the latest Wi-Fi 6 standard 802.11ax is ideal for businesses and homes. Modern and discreet design allows for placement close to users for optimal performance. In the 5GHz band, it reaches a transmission speed of up to 4800Mb/s (4x4 MIMO) and in 2.4GHz 574Mb/s (2x2 MIMO).

Suitable for indoor and outdoor use thanks to IPX5 protection. Seamless integration and management with the UniFi network solution. Included in the package are brackets for wall, pole and table mounting.

Key properties

• Wi-Fi 6 technology - 802.11a/b/g/n/ac/ax
• 5GHz throughput up to 4,800Mb/s - 160MHz, 4x4 MIMO
• 2.4GHz bandwidth up to 574Mb/s - 2x2 MIMO
• 802.3af POE power supply
• WPA3 encryption support
• central unit control

To manage the device, you need to download the original software called UniFi Network application from the official website, thanks to which the entire network can be controlled.
The indisputable advantage of the UniFi Network application is that it is completely free without any restrictions!
This central management will allow you to upload maps and set basic parameters as well as advanced functions such as SSID, guest account, start page, traffic statistics and the list and status of associated clients always easily and quickly.

Advantages of the UniFi solution

• Fast Roaming - uninterrupted transition between individual APs
• Wireless uplink (suitable where it is not possible to get a data cable)
• up to 8 SSIDs
• detailed traffic statistics
• Guest network
• Load balance - maintaining an even load/switching clients
• rate limiting for each SSID

Package contents

• device
• holders - wall, column, table
• zip ties
• Gigabit PoE power adapter 48V/0.32A
• power cable
• screws

Technical parameters

Wireless features
Wireless frequency: 2.4 + 5GHz (dual band)
WiFi standards: 802.11ac, 802.11ax, 802.11n, 802.11a, 802.11b/g
MU-MIMO: Yes
Transmission speed - 5GHz [Mb/s]: 4804
Transmission speed - 2.4GHz [Mbps]: 574
2.4GHz Transmit Power [dBm]: 22
5GHz Transmit Power [dBm]: 26
Encryption: WPA, WPA2, WPA3
2.4GHz OUT: 2x2
5GHz OUTSIDE: 4x4
Antenna type: Built-in
Number of built-in antennas: 6
Roaming: Yes

Connectors and interfaces
LAN speed: (1) 10/100/1000Mbps
Gigabit LAN: Yes

Others: Bluetooth

Power supply
Power supply via PoE: 802.3af, 44 .. 57V DC
PoE types: PoE-In (only)
Max. power consumption [W]: 11.4

Physical characteristics
Use: Internal
Operating temperature [°C]: -30 to 60
Weight [g]: 400
Width [mm]: 49
Height [mm]: 160
Depth [mm]: 49
